Runva EWX9500-Q 12V with Synthetic Rope

$925.00

Limited Lifetime Warranty



  • 9,500LB LINE PULL CAPACITY
  • FAST LINE SPEED
  • SUPER LOW 110:1 GEAR RATIO
  • MASSIVE 8.9HP MOTOR
  • AVAILABLE IN 12V AND 24V
  • COMPETITION PROVEN

The Runva EWX9500-Q is one of our oldest models and still a very popular option. Featuring 9,500lb of line pull from the very powerful and reliable 8.9HP motor. (This would have to be one of our most powerful motors yet). The gearbox is a three stage planetary setup with a low 110:1 gear ratio for increased line speed.

This model is excellent for those seeking increased line speed, but still needing a winch that is relatively compact to fit most 4X4 Winch Bars/Bullbars.

RATED LINE PULL9,500LB (4,309KG)
MOTOR(12V) 6.6KW/8.9HP; (24V) 8.0KW/10.7HP
GEAR TRAINFULL STEEL PLANETARY
GEAR RATIO110:1
CLUTCH TYPESLIDING RING GEAR CLUTCH
CLUTCH HANDLE POSITIONGEARBOX CAN BE ROTATED
BRAKEAUTOMATIC LOAD HOLDING SCREW CONE
CABLE TYPESYNTHETIC ROPE
CABLE SIZE10MM X 25.5M
DRUM SIZE63MM X 223MM
MOUNTING BOLT PATTERN254MM X 114.3MM (4X M10 BOLTS)
OVERALL DIMENSIONS577MM X 163MM X 217MM
REMOTE CONTROLHEAVY DUTY HANDHELD + WIRELESS
BATTERY LEADS 2X 1.8M HEAVY DUTY LEADS
FINISHGREY POWDER COAT
WARRANTYLIMITED 5 YEAR ELECTRICAL AND LIFETIME MECHANICAL WARRANTY
sku EWX9500Q12VD
Shipping Weight 33.50kg
Shipping Width 0.330m
Shipping Height 0.330m
Shipping Length 0.635m
dimensions
LINE PULL lb (kg) LINE SPEED ft/min (m/min) MOTOR CURRENT (amp) LAYER OF CABLE RATED LINE PULL lb (kg) TOTAL ROPE ON DRUM ft (m)
  12V DC 24V DC 12V DC 24V DC
0 (0) 50.2 (15.3) 53.2 (16.2) 90 70 1 9,500 (4,309) 17.4 (5.3)
1,000 (454) 42.7 (13.0) 49.2 (15.0) 150 120 2 7,706 (3,495) 39.4 (12.0)
4,000 (1,814) 17.1 (5.2) 18.4 (5.6) 300 240 3 6,482 (2,940) 65.0 (19.8)
6,000 (2,722) 11.8 (3.6) 15.8 (4.8) 400 290 4 5,593 (2,537) 85.3 (26.0)
8,000 (3,629) 9.5 (2.9) 13.1 (4.0) 470 350
9,500 (4,309) 8.9 (2.7) 11.8 (3.6) 550 400

(THE MAXIMUM LINE PULL CAPACITY IS BASED ON THE FIRST LAYER OF CABLE/ROPE)
